Key Features:

  • World-class components offer impeccable sound experience
  • Defined and accurate rotatable 80° x 50° horn minimises reflection and feedback issues
  • Use in conjunction with AA B10 subs for extended low-frequency delivery
  • Hi-Fi grade components give an extended 54Hz frequency response
  • RAL colours are available on request

SKU: AA 6F

834 Viewing this right now...
Hurry !! Only 1 left in stock

Details

Meticulously designed to perceptively interact with the space around them, the Audible Avenue AA 6F 8-ohm passive, compact, point-source speakers represent the finest in sound reinforcement solutions for speech and music reproduction application – be it infills for portable applications, or as a key system ingredient in fixed installation use.



The AA 6F brings together best-in-class components as it features the use of Faital PRO’s acclaimed 6FE100 midrange mid-bass driver, working seamlessly with a high-quality custom-designed rotatable horn and the high-performance DE250 compression driver – both from reputed Indian manufacturer Aerons India. The precise tuning of these components means that the AA 6F assures defined and accurate dispersion with 80° x 50° coverage; while the internal passive crossover has been harmonized to ensure a flat, usable frequency response of 54 Hz to 18 kHz (-10 dB) with a maximum SPL of 115 dB (peak). This ensures that the AA 6F can deliver the kind of crisp and detailed soundscape that is rarely seen in other loudspeaker models in its class. Also, since all models of the AA Series share the same voicing characteristics, this means that system designers can instinctively use the AA 6F simultaneously with other members of the AA series and stay assured of maintaining a consistent tonal signature across the space.



Visually appealing – the AA 6F sports an elegant design with a reticulated grill front and acrylic textured paint finish offering a premium look that allows it to blend into any kind of venue – be it fine dining spaces or places of worship, entertainment destinations, or even a private viewing theatre. On the other hand, multiple integrated fixing points and mounting options with pan and tilt brackets along with the inclusion of a rotatable horn ensures that the compact profile AA 6F can be placed with pin-point accuracy even in the most challenging rooms, to offer a sound experience that makes sure that the venue sounds every bit as great as it looks.

Readily Available in black but custom RAL colors are available on request.



Specifications

Design

Full Range cabinet, bass reflex

Components

1x6” Faitalpro 6FE100

1x HF DE250 Aerons India

1x Horn Aerons India

Connectors

2 x 4 pole speakON® connectors

Dimensions

447 x 220 x 290 mm (without C clamp)

Net Weight

11.2Kg (1 cabinet without C clamp)

Shipping Weight

28Kg (2 cabinets with C clamps per carton)

Colour

Black

Options

RAL colors on request

Rigging

8 x M8 mounting points for installation brackets and C clamp

5 x M8 mounting points for wall bracket

 Fitted as standard

Pole Mount

Additional data

MDF construction, with durable scratch-resistant black textured paint finish, kick-proof steel grill, Wall Mount C clamp





Impedance

8 ohms

Power handling

100 watts

Max power handling

200 watts

Sensitivity

92dB

Max SPL

112dB

Peak SPL

115dB

Frequency Response: - 3dB

70Hz to 18Khz

Usable Frequency: (-10dB)

54Hz to 18Khz

Dispersion

80° x 50°





SYSTEM OPERATIONS

Recommended amplification

150 Watt – 200 Watt

System controller

Aerons India DSP 4080

Recommended filter setting

Download from the website.
