AJ11002 is a class AB two-channel power amplifier elaborately designed for the professional market. With a modular and compact design, elegant outlook, precise and comprehensive protection system, excellent sound performance, and high performance-price ratio, it ensures very good profit margins for our business partners.
Features
Unique Linear Limiter Protection Circuit (LXTM circuit)
The protection value of the LXTM linear limiter protection circuit can reach 8V. It can track the dynamics of temperature, power, and frequency in time and adjust the limiter strength automatically to ensure that the system always runs in a safe environment and ensures the dynamic effect of the entire audio system.
Unique and Efficient Crosstalk Shielding Design
When designing and selecting components in the R & D stage, the anti-interference ability of the circuit was fully considered. AJ11002 will not be interfered with by peripheral electronic equipment, which effectively solves the headache of crosstalk.
Perfect Protection System
Limiter protection/ Soft-start protection/DC protection/Short-circuit protection/Overheat protection/Output overload protection
Specifications
| Dynamic Power |
2x 700W(8Ω stereo) |
| 2x 1100W(4Ω stereo) | |
| 1x 2200W(8Ω bridge) | |
| Total harmonic distortion（ 8Ω & 20Hz-20kHz，half power） | ≤ 0.1% |
| Slew rate | ≥ 25 V/uS |
| Frequency response（1W 8Ω stereo） | 20 Hz-20kHz ± 0.5dB |
| Damping（1kHz &8Ω） | ≥ 200 |
| Signal-to-noise ratio (A-weighted, rated power 8Ω) | ≥ 100dB |
| Crosstalk (1kHz, rated power 8Ω) | ≥ 60 dB |
| Input impedance | Unbalanced 10kΩ , balanced 20kΩ |
| Output circuitry | Class AB |
| Protection | DC protection/short circuit protection/overheat protection/ output overload protection/soft start protection |
| Dimension(WxHxD) | 483 x88x377mm |
| Net weight | 16.0Kg |
