Details
NOMINAL SPECIFICATIONS
| Nominal Diameter | 300 mm (12 in) |
| Overall Diameter | 316 mm (12.44 in) |
| Bolt Circle Diameter | 298.5 mm (11.75 in) |
| Baffle Cutout Diameter | 284 mm (11.18 in) |
| Depth | 155.75 mm (6.13 in) |
| Flange and Gasket Thickness | 12.5 mm (0.49 in) |
| Net Weight | 4.2 kg (9.3 lb) |
| Shipping Box (Single Carton Box) |
350 x 346 x 216 mm (13.8 x 13.6 x 8.5 in) |
| Shipping Weight | 5 kg (11.0 lb) |
Specifications
TECHNICAL PARAMETERS
| Nominal Impedance | 8 Ohm |
| Minimum Impedance | 6.3 Ohm |
| AES Power Handling (1) | 600 W |
| Maximum Power Handling (2) | 1200 W |
| Sensitivity (1W/1m) | 98 dB |
| Frequency Range | 50÷4000 Hz |
| Voice Coil Diameter | 77 mm (3 in) |
| Winding Material | Al |
| Former Material | Glass Fiber |
| Winding Depth | 18.5 mm (0.71 in) |
| Magnetic Gap Depth | 12 mm (0.47 in) |
| Flux Density | 1.1 T |
| Magnet | Neodymium Slug |
| Basket Material | Aluminum |
| Demodulation | Aluminum Ring |
| Cone Surround (3) | Triple Roll |
| NET Air Volume filled by Loudspeaker | 2.4 dm^3 (0.085 ft^3) |
| Spider Profile | 1x variable height waves |
